O.D.(Inch) |
Bottom Wall Tickness Tw |
Fin Groove Depth Hf |
|
Inch |
mm |
Inch |
mm |
Inch |
mm |
|
0.1575 |
4 |
0.008 ~ 0.012 |
0.20 ~ 0.30 |
0.004 ~ 0.006 |
0.10 ~ 0.15 |
|
0.1875 |
4.76 |
0.008 ~ 0.014 |
0.20 ~ 0.35 |
0.004 ~ 0.006 |
0.10 ~ 0.15 |
|
0.1970 |
5 |
0.008 ~ 0.014 |
0.20 ~ 0.35 |
0.004 ~ 0.006 |
0.10 ~ 0.15 |
|
0.2363 |
6 |
0.008 ~ 0.014 |
0.20 ~ 0.35 |
0.004 ~ 0.008 |
0.10 ~ 0.20 |
|
0.2500 |
6.35 |
0.008 ~ 0.014 |
0.20 ~ 0.35 |
0.004 ~ 0.008 |
0.10 ~ 0.20 |
|
0.2750 |
7 |
0.010 ~ 0.016 |
0.20 ~ 0.41 |
0.004 ~ 0.010 |
0.10 ~ 0.25 |
|
0.3125 |
7.94 |
0.010 ~ 0.016 |
0.20 ~ 0.41 |
0.004 ~ 0.010 |
0.10 ~ 0.25 |
|
0.3750 |
9.52 |
0.010 ~ 0.016 |
0.20 ~ 0.46 |
0.004 ~ 0.012 |
0.10 ~ 0.30 |
|
|
|
■ Apex Angle(Tolerance)a 30 ~ 90 |
|
|
■ Helix Angle Deg(Tolerance) 15 ~ 30 |
|
|
■ Number of Tooth(Number) 40 ~ 70 |
|
|
|
| |
