Product Introduction
1. All connections are copper welded.
2. Available full-size porting maintains unrestricted gas flow.
3. Machined steel housing built to exacting tolerances of 0.005mm.
4. The sign eliminate the problem of inside leakage.
5. Careful selection guarantees the quality.
1/4 Flare
|
TYPE |
A(in) |
Porting |
B(in) |
C(in) |
D(in) |
E(in) |
F(in) |
G(in) |
H(in) |
I(in) |
|
BIV102-1 |
3/8 |
Full |
1/2 |
1/4
Flare |
2-3/16 |
2-1/4 |
4-3/8 |
3-1/4 |
2-1/8 |
3-1/16 |
|
BIV102-2 |
Full |
5/8 |
2-5/16 |
4-5/8 |
|
BIV102-3 |
1/2 |
Full |
5/8 |
2-5/16 |
4-5/8 |
|
BIV102-4 |
|
3/4 |
2-3/8 |
4-11/16 |
|
BIV102-5 |
|
7/8 |
2-1/2 |
5 |
|
BIV103-1 |
Full |
3/4 |
2-3/8 |
4-11/16 |
3-3/8 |
3-7/8 |
|
BIV103-2 |
|
7/8 |
2-1/2 |
5 |
|
BIV106-0 |
Full |
3/4 |
2-3/8 |
2-1/2 |
5 |
3-1/2 |
2-5/8 |
4-7/16 |
|
BIV106-1 |
5/8 |
Full |
7/8 |
2-1/2 |
2-11/16 |
5-3/8 |
|
BIV106-2 |
|
1-1/8 |
3-1/8 |
6-1/4 |
|
BIV107-1 |
7/8 |
Full |
1-1/8 |
2-3/4 |
3-1/4 |
6-1/2 |
3-5/8 |
2-7/8 |
5-5/8 |
|
BIV107-2 |
|
1-3/8 |
3-1/2 |
6-15/16 |
|
BIV109-1 |
1-1/8 |
Full |
1-3/8 |
3-3/8 |
3-5/8 |
7-3/16 |
3-3/4 |
3-1/8 |
6-5/16 |
|
BIV109-2 |
|
1-5/8 |
4-1/8 |
8-3/16 |
|
BIV112-1 |
1-3/8 |
Full |
1-5/8 |
3-15/16 |
4-7/16 |
8-7/8 |
4 |
4 |
8-1/4 |
|
BIV112-2 |
|
2-1/8 |
5-1/4 |
10-9/16 |
3/8 Flare
|
TYPE |
A(in) |
Porting |
B(in) |
C(in) |
D(in) |
E(in) |
F(in) |
G(in) |
H(in) |
I(in) |
|
BIV115-1 |
1-5/8 |
Full |
2-1/8 |
3/8
Flare |
5-1/4 |
5-1/2 |
10-15/16 |
6-1/2 |
5-1/2 |
11-1/2 |
|
BIV115-2 |
2-1/8 |
|
2-5/8 |
5-1/4 |
5-1/2 |
10-15/16 |
6-1/2 |
5-1/2 |
11-1/2 |
|
BIV118-1 |
2-1/8 |
Full |
2-5/8 |
6-1/8 |
6-3/8 |
13-11/16 |
6-15/16 |
6-3/4 |
12-1/4 |
|
BIV121-1 |
2-5/8 |
Full |
3-1/8 |
6-5/8 |
7-1/8 |
14-3/16 |
7-1/8 |
7-1/4 |
14-5/8 | |
